200kg/Hour PP Strap Production Line 0.4mm - 1.2mm Pp Strap Manufacturing Machine

200kg/Hour PP Strap Production Line 0.4mm - 1.2mm Pp Strap Manufacturing Machine
200kg/Hour PP Strap Production Line 0.4mm - 1.2mm Pp Strap Manufacturing Machine 200kg/Hour PP Strap Production Line 0.4mm - 1.2mm Pp Strap Manufacturing Machine 200kg/Hour PP Strap Production Line 0.4mm - 1.2mm Pp Strap Manufacturing Machine

Large Image :  200kg/Hour PP Strap Production Line 0.4mm - 1.2mm Pp Strap Manufacturing Machine

Product Details:
Place of Origin: Shanghai, China
Brand Name: CHLOE
Certification: CE ISO
Model Number: JXZL STRAP–PP-350–8–500
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: Negotiate
Packaging Details: Wooden Box
Delivery Time: 120Days
Payment Terms: T/T
Supply Ability: 5 Sets/month
Contact Now Chat Now

200kg/Hour PP Strap Production Line 0.4mm - 1.2mm Pp Strap Manufacturing Machine

Description
Voltage: 3×380V; 60Hz, 3-phase With Neutral Wire Machine Type: PP Strap Production Line
Application: Wire, PIPE, Sheet, Filament Key Selling Points: High Productivity
Warranty: 1 Year
Highlight:

1.2mm pp strap manufacturing machine

,

200kg/hour pp strap making machine

,

200kg/hour pp strap manufacturing machine

Dual Extrusion Co-extrusion PP Strapping Tape Extrusion Line | 200kg/h High Output PP Packing Strap Production Machine
Technical Specifications
Item Specification
PROJECT EXTRUSION LINE FOR THE PRODUCTION OF PP STRAPPING TAPE
TYPE JXZL STRAP-PP-350-8-500
(Key Specs: Product-Raw Material-Hourly Output-Number of Lines-Roll Width)
RESIN TYPE Polypropylene (PP), Melt Flow Index (MFI): 0.5~2.4 g/10min
WIDTH 5-15 mm
THICKNESS 0.4 mm - 1.2 mm
OUTPUT OF EXTRUDER up to 200 kg/h
OPERATION SIDE right to left
COLOR FINISH RAL7035 light grey, structure RAL5002
CLIENT'S MAINS VOLTAGE 3*380V; 60Hz, 3-phase with neutral wire
Product Overview
This extrusion line is professionally designed for high-efficiency production of PP strapping tape, with a maximum output of up to 200 kg/h, stable performance and high automation. It adopts a dual-extrusion co-extrusion system (100mm & 70mm high-strength nitriding steel screws, L/D 30:1), matched with continuous hydraulic screen changers and precision gear metering pumps, to achieve uniform plasticization, stable extrusion and precise melt control.
The full-line configuration includes automatic feeding & gravimetric mixing system, multi-stage temperature-controlled stretching oven, precision embossing, printing, shaping and cooling units, equipped with high-precision temperature control (±1°C) and synchronous drive control system, ensuring the strapping tape with uniform thickness (0.4-1.2mm), stable width (5-15mm), excellent mechanical strength and surface quality.
The whole line adopts fully computerized control system, supporting recipe management, online monitoring, fault diagnosis and remote assistance; with standardized electrical configuration (3*380V, 60Hz), high-quality brand components, safe and reliable operation. The line features compact structure, smooth operation, low energy consumption, easy operation and maintenance, which can meet the mass and stable production requirements of high-quality PP strapping tape.
PP Strapping Tape Extrusion Line Production Equipment
Complete Line Configuration
Extrusion Line for the Production of PP Strapping Tape, Equipped with:
  • Material feeding system
  • Extrusion group 1
  • Extrusion group 2
  • Filter 1
  • Filter 2
  • Spin pump group 1
  • Spin pump group 2
  • Die head group
  • Quench tank group
  • 1ST ROLL STAND UNIT
  • Pre-Stretching Oven
  • Calendering Machine Set
  • 2ND ROLL STAND UNIT
  • Printing Module
  • 2 Embossing units
  • Relaxing oven
  • Water cooling tank
  • Water Removal System
  • 3RD ROLL STAND UNIT
  • Conveyor Belt plate to prevent strap jam
  • 4 φ200mm Automatic winders
  • 2 φ406mm Semi-Automatic winders
  • Cooling tower
  • Fully computerized control system
  • Test run at Shanghai facilities
  • Technical documentation
Winding Configuration: 4 positions (φ200mm Automatic winder) + 2 positions (φ406mm Semi-Automatic winder)
Frequently Asked Questions
How do you ensure machine quality?
To ensure the machine is qualified before delivery to our customer, we always arrange production testing. Customers can assign the testing strap's specification. Customers can join the testing process or we can provide video documentation.
Do you have a professional team for mechanical equipment development?
Our R&D team comprises seasoned engineers and specialists from the plastic machinery sector. We have independently developed and manufactured the first fully intelligent strapping winders in China, exporting our products to Europe, the United States, and other regions.
What are the advantages of your strapping and packaging equipment?
Yicheng Automation is committed to innovation, continuously developing cutting-edge technologies in the packaging plastics machinery sector. With specialized expertise in fully intelligent plastic strapping rewinding systems, we deliver high cost-performance solutions engineered for customer success.
What are your after-sales services?
Warranty: One year from the delivery date indicated on the Bill of Lading (B/L).
During the warranty period, the seller provides free parts and online service (excluding any specified exclusions).
After the warranty period, the seller supplies parts at cost.
Lifelong responsibility for equipment support.
